Standards
| Model | UA2M3AEGV-42M/C |
| Sensor | IMX249 |
| Image Mode | Color / Mono |
| Optical Size | 13.40mm |
| Resolution | 1920 * 1200 |
| Pixel Size | 5.86μm * 5.86μm |
| Max Frame Rate | 46fps |
| Data Format | Monochrome camera: Mono8/10/10p Color camera: Mono8/Bayer8/10/10p/RGB8/YUV422_8 |
| Dynamic Range | ≥73.2dB |
| Data Rate | 106MB/s |
| Trigger Mode | Free-Run / External Pulse / External PWM |
| External Trigger | External I/O Signal / Software Trigger Signal |
| Exposure Control | Pulse Width Control / Timed / Auto Function |
| Exposure Time | 32μs-10s |
| Analog Gain | 0-24dB |
| Digital Gain | 0.1-8.0x |
| Lens Mount | C Mount |
| Data Interface | GigE Vision |
| Power Supply | DC 12~24V (±10%) 0.5A or PoE |
| Power Consumption | 3.2W (DC) or 4.1W (PoE) |
| Dimensions | 29.0mm x 29.0mm x 60.9mm |
| Operating Temperature | 0-55℃ |
| Storage Temperature | -20-75℃ |
| Product Weight | 89.3g |
