Standards
| Model | TTS65MCXP-31M/C |
| Sensor Type | GMAX3265 |
| Image Mode | Mono / Color |
| Optical Size | 37.36 mm |
| Resolution | 9344 * 7000 |
| Pixel Size | 3.2μm * 3.2μm |
| Max Frame Rate | 31.59fps@8bit, 23.69fps@10/12bit |
| Bit Depth | 8/10/12 bit |
| Dynamic Range | ≥62 dB |
| Data Rate | 2324MB/s |
| Trigger Mode | Free Run / External Trigger / External PWM |
| Trigger Source | External IO / CXP Trigger |
| Exposure Control | Timed / Pulse Width Control |
| Exposure Time | 14μs-10s(Step:1μs) |
| Analog Gain | 0-64dB |
| Digital Gain | 0.1-8.0× |
| Lens Mount | M42 * 1 / M58 * 0.75 / M72 * 0.75 / F Mount |
| Data Interface | CoaXPress |
| Power Connector | Hirose HR10A-7R-6PB(Male) |
| Power Supply | DC12V±10% 5A |
| Power Consumption | 45.8W |
| Cooling Mode | TEC Cooling |
| TEC Cooling | About 12℃ below ambient temperature |
| Dimensions |
M42: 111.0mm × 111.0mm × 123.0mm M58: 111.0mm × 111.0mm × 89.0mm M58: 111.0mm × 111.0mm × 97.5mm M72: 111.0mm × 111.0mm × 97.1mm F Mount: 111.0mm × 111.0mm × 124.0mm |
| Operating Temperature | 0-45℃ |
| Storage Temperature | -20-75℃ |
| Product Weight | 1599.7g |
