Standards
| Model | TTS61M2CL-13M/C |
| Sensor Type | IMX455 |
| Image Mode | Mono / Color |
| Optical Size | 43.24 mm |
| Resolution | 9568 * 6380 |
| Pixel Size | 3.76μm * 3.76μm |
| Max Frame Rate | 13.06fps@10Tap, 10.34fps@8Tap, 5.18fps@4Tap |
| Bit Depth | 8/10/12 bit |
| Dynamic Range | ≥75.8 dB |
| Data Rate | 797MB/s |
| Trigger Mode | Free-Run / External Pulse / External PWM |
| Trigger Source | Camera Link CC / External IO |
| Exposure Control | Timed / Pulse Width Control |
| Exposure Time | 120μs-60s(Step:60μs@4Tap; 30μs@8Tap; 23.75μs@10Tap) |
| Analog Gain | 0-96dB |
| Digital Gain | 0.01-8.00× |
| Lens Mount | F Mount |
| Data Interface | Camera Link |
| Power Connector | Hirose HR10A-7R-6PB(Male) |
| Power Supply | DC12V±10% 5A |
| Power Consumption | 50.0 W |
| Cooling Mode | TEC Cooling |
| TEC Cooling | About 20℃ below ambient temperature |
| Dimensions | 111.0mm(W) x 111.0mm(H) x 131.8mm(D) |
| Operating Temperature | 0-50℃ |
| Storage Temperature | -20-75℃ |
| Product Weight | 1824.4g |
