Standards
| Model | TS65MCL-12M/C |
| Sensor Type | GMAX3265 |
| Image Mode | Color / Mono |
| Optical Size | 37.36 mm |
| Resolution | 9344 * 7000 |
| Pixel Size | 3.2μm * 3.2μm |
| Max Frame Rate | 12.47fps@8bit; 10.16fps@10bit; 5.08fps@12bit |
| Bit Depth | 8/10/12 bit |
| Dynamic Range | ≥62 dB |
| Data Rate | 816 MB/s |
| Trigger Mode | Free Run / External Trigger / External PWM |
| Trigger Source | Camera Link CC / External IO |
| Exposure Control | Timed / Pulse Width Control |
| Exposure Time | 37μs-10s(Step:1μs) |
| Analog Gain | 0-64dB |
| Digital Gain | 0.01-8.00× |
| Lens Mount | M58 * 0.75 |
| Data Interface | Camera Link |
| Power Connector | Hirose HR10A-7R-6PB(Male) |
| Power Supply | DC12V±10% 1.5A |
| Power Consumption | 8.6 W |
| Dimensions | 67.0mm(W) × 67.0mm(H) × 71.4mm(D) |
| Operating Temperature | 0-65℃ |
| Storage Temperature | -20-75℃ |
| Product Weight | 390.7g |
