Standards
| Model | TS5MSCL-36M/C |
| Sensor | Global Shutter CMOS |
| Image Mode | Color / Mono |
| Optical Size | 11.01 mm |
| Resolution | 2448 * 2048 |
| Pixel Size | 3.45μm * 3.45μm |
| Max Frame Rate | 32.54 fps@2Tap，36.70fps@4/8/10Tap |
| Bit Depth | 8/10/12bit |
| Dynamic Range | ≥71.6 dB |
| Data Rate | 276MB/s |
| Trigger Mode | Free run / External trigger |
| Trigger Source | Camera Link CC1 / External IO |
| Exposure Control | Pulse Width Control, Timed |
| Exposure Time | 13μs-10s(step:1µs) |
| Analog Gain | 1-24dB |
| Digital Gain | 0.004-8.000x |
| Lens Interface | C Mount |
| Data Interface | Camera Link |
| Power Interface | M5 4-pin |
| Power Supply | DC12-24V(±10%) 0.5A |
| Power Consumption | 3.2W |
| Dimensions | 29.0mm(W) x 29.0mm(H) x 54.9mm(D) |
| Operating Temperature | 0-55℃ |
| Storage Temperature | -20-75℃ |
