Standards
| Model | PL8KCL-33KC |
| Sensor | Global Shutter CMOS |
| Image Mode | Color |
| Optical Size | 41.60 mm |
| Resolution | 8320 * 12 |
| Pixel Size | 5μm * 5μm |
| Max Line Rate | 32.6kHz@3Tap，19.6kHz@2Tap，9.8kHz@1Tap |
| Bit Depth | 8/10 bit |
| Dynamic Range | ≥58 dB |
| Data Rate | 820 MB/s |
| Trigger Mode | Free-Run / External Pulse / External PWM |
| Exposure Control | Timed / Pulse Width Control |
| Exposure Time | 1μs-63997μs(Step:0.013μs) |
| Analog Gain | 1/2/4x |
| Digital Gain | 0.01-8.00x |
| Data Interface | Camera Link |
| Lens Mount | M72 * 0.75 |
| Power Connector | Hirose HR10A-7R-6PB(Male) |
| Power Supply | DC12V±10% 2.0A |
| Power Dissipation | 15.9W |
| Dimensions | 79.6mm x 139.5mm x 71.5mm |
| Operating Temperature | 0-50℃ |
| Storage Temperature | -20-75℃ |
| Product Weight | 883.9g |
