Standards
| Model | PL8KCL-100KT |
| Sensor | Global Shutter CMOS |
| Image Mode | Mono |
| Optical Size | 41.60 mm |
| Resolution | 8320 * 8 |
| Pixel Size | 5μm * 5μm |
| Max Line Rate | 99.8kHz@10Tap，80.1kHz@8Tap，40.1kHz@4Tap，20.0kHz@2Tap |
| Bit Depth | 8/10/12 bit |
| Dynamic Range | ≥54 dB |
| Data Rate | 850 MB/s |
| Trigger Mode | Free-Run / External Pulse / External PWM |
| Exposure Control | Timed / Pulse Width Control |
| Exposure Time | 3μs-63997μs(Step:0.01μs) |
| Analog Gain | 1/2/4x |
| Digital Gain | 1-8x |
| Lens Mount | M72 * 0.75 / F Mount |
| Data Interface | Camera Link |
| Power Connector | Hirose HR10A-7R-6PB(Male) |
| Power Supply | DC12V±10% 2.5A |
| Power Dissipation | 18.0 W |
| Dimensions | 79.6mm(W) x 139.5mm(H) x 71.5mm(D) |
| Operating Temperature | 0-55℃ |
| Storage Temperature | -20-75℃ |
| Product Weight | 883.9g |
